| Gases Sensed | Methane (CH4), Non-methane Hydrocarbons (NMHC), Total Hydrocarbons (THC) |
|---|---|
| Technology |
The 3010 MINIFID Portable heated FID VOC analyser is a small, self contained, and fully portable analyser. It is equally convenient for use on the laboratory bench or as a portable on-site measurement tool. This portable FID features the same detection system as the S4 Solar range of FIDs. It is supplied with a 5m heated sample line and built-in controller as standard. The bottle rack may be detached for use with standard, full sized gas cylinders.
The 3010 MINIFID Portable heated FID VOC analyser is a small, self contained, and fully portable analyser. It is equally convenient for use on the laboratory bench or as a portable on-site measurement tool. This portable FID features the same detection system as the S4 Solar range of FIDs. It is supplied with a 5m heated sample line and built-in controller as standard. The bottle rack may be detached for use with standard, full sized gas cylinders.
| Gases Sensed | Methane (CH4), Non-methane Hydrocarbons (NMHC), Total Hydrocarbons (THC) |
|---|---|
| Technology |
• Designed for portability
• Military style design
• Thousands sold globally
• Many still in operation after years of rigorous work
• Easy to use
• Warm-up typically 20 mins
• No microprocessor or software
• Just 5 simple functions
• 0-10v output or optional logger
Relevant Standards
• EN12619
• EN15267-3
• EN15267-4
• ISO25140
• Method 25
• Method 25a
• EURO VI/VII
• ARP1256D
• CPA 2015-C174
• Air separation
• Solvent/VOC abatement/scrubber efficiency
• Thermal oxidiser control/monitoring
• Process control
• Process emissions monitoring
• Flue gas emissions monitoring
• Combustion research
• Biomass combustion monitoring
• Carbon bed breakthrough detection
• Gas purity
• Locomotive/automotive/marine combustion engine exhaust emissions
• Gas turbine exhaust emissions
• Vehicle emissions
• Source emissions
• Stack testing
• Fermentation monitoring
• Continuous emissions monitoring (CEM)
• Container leakage control/monitoring
• Safety monitoring
• Compliance monitoring
• Landfill
• Semiconductor manufacturing process monitoring
• Part B processes
• Environmental permit
• Paintshop emissions
• Solvent emissions
• Portable FID
• Portable VOC emissions
• Evaporative emissions
SENSITIVITY: 0.1% of range
LINEARITY: 2% of measured value
DRIFT +/-0.2ppm or 2% range per week, whichever greater
NOISE +/-0.1ppm or 1% range, whichever greater
RESPONSE TIME: T90 in 2 seconds
POWER: 110V AC or 220V AC, 500 Watts
HEATED SAMPLE LINE TEMPERATURE: 190 o C
ANALYSER SAMPLING SYSTEM TEMPERATURE 190 o C
WEIGHT WITH GAS BOTTLES 12 Kg (25 lbs)
WEIGHT WITHOUT GAS BOTTLE 9Kg (18 lbs)
DIMENSIONS 210 x 300 x 240mm
SAFETY INTERLOCK Fuel shuts off if flame goes out
SAMPLE INTERLOCK Sample pump and heated line cannot start until analyser is at set temperature
SAMPLE FILTER 0.4 microns (accessible from rear of analyser)
SAMPLE FLOW 0.4-3 l/min. (internal sample pump)
SAMPLE LINE LENGTHS 5 or 10 metres of 6mm Teflon heated to 190 o C controlled by the analyser. Plug in socket is wired so that the 5 and 10 metre lines connect to different contacts. Other lengths up to 15m on request
OPERATING CONTROLS 3 ½ digit LCD display. Temperature reading for heated line & sampling system. Ignition switch. Range select and calibration controls
RECORDER OUTPUTS 0-10 V DC and 4-20 mAmp isolated
DATA LOGGER Built into analyser with software for PC to log to spreadsheet
GAS – QUICK CONNECTS Colour coded for fuel and calibration gas
GAS BOTTLE CAPACITY 1 litre water capacity
FUEL CONSUMPTION H2 35ml/ min
FUEL CONSUMPTION. H2/HE 180ml/min
CAL GAS FLOW RATE 0.4 l/min
ZERO AIR Internally generated with carbon or catalytic scrubber
FLAME AIR Internally generated with carbon or catalytic scrubber
ANALYSER WEATHER PROTECTION IP 20 (IP 55 when fitted with tailored fabric cover)
OPERATING AMBIENT TEMPERATURE +5 to +40 o C
Power Supply:
110VAC (Standard)
220VAC
Plug Type:
Standard (Power supply dependant)
Other (please specify)
No plug option – customer to arrange locally
Fuel Gas:
H2He (Standard)
H2 Fuel
Calibration Gas:
500ppm C3H8/air (Standard)
500ppm CH4/air
Ranges:
0-10,000ppm FSD (Standard)
0-10% High Range
Onboard Data Logger:
Yes
No
Internal Air Purifier*:
Carbon Scrubber (Standard)
AS90
Synthetic Air/Clean Air Supply
Heated Line:
3 metres
5 metres
10 metres
15 metres
None
Gas Bottles:
Yes
No
Gas Bottles* (Fuel & Calibration gas bottles with regulator):
Empty
Filled
Quick Connectors (Applicable only if MiniFID purchased without gas bottles):
Notes:
– Extra field replaceable carbon scrubber can be supplied at an additional cost.
– AS90 is a built-in heated catalyst air purifier to supply hydrocarbon free air for increased stability and drift.
– Carbon scrubber or AS90 is not required if customer can already provide clean air supply.
– Stainless steel with a 10micron sintered end filter to protect the sample line.
– Due to shipping constraints for hazardous gases, we recommend purchasing empty gas bottles and filling them at local gas supplier.
– Sintered 10micron stainless steel sample probe*:
