S4 SOLAR – Heated FID VOC analyser

The S4 SOLAR Heated FID VOC analyser employs Flame Ionisation Detectors (FID) technology and is designed for a standard 19” rack, with heated and non-heated options. A dual detector version is also available for the simultaneous measurement of both methane and non-methane hydrocarbons.

Optional Configuration

Add to Quote

Description

The S4 SOLAR Heated FID VOC analyser employs Flame Ionisation Detectors (FID) technology and is designed for a standard 19” rack, with heated and non-heated options. A dual detector version is also available for the simultaneous measurement of both methane and non-methane hydrocarbons.

Additional information

Gases Sensed

, , ,

Technology

Key Features

• Fixed and portable versions

• ‘Hot’ and ‘Cold’ versions

• Totally automatic operation

• Wireless tablet Software suite for use over ethernet or RS232

• Precision monobloc FID

• Trace PPM measurements standard

• High range % available

Relevant standards:

  • EN12619
  • EN15267-3
  • ISO25140
  • Method 25
  • Method 25a
  • EURO VI/VII
  • ARP1256D
  • CPA 2015-C174

Applications

• Air separation

• Flue gas emissions monitoring

• Process emissions monitoring

• Solvent/VOC abatement/scrubber efficiency

• Thermal oxidiser control/monitoring

• Process control

• Combustion research

• Biomass combustion monitoring

• Carbon bed breakthrough detection

• Gas purity

• Locomotive/automotive/marine combustion engine exhaust emissions

• Gas turbine exhaust emissions

• Vehicle emissions

• Source emissions

• Stack testing

• Fermentation monitoring

• Continuous emissions monitoring (CEM)

• Container leakage control/monitoring

• Safety monitoring

• Compliance monitoring

• Semiconductor manufacturing process monitoring

• Part B processes

• Environmental permit

• Paintshop emissions

• Solvent emissions

• Portable FID

• Portable VOC emissions

• Evaporative emissions

Documentation

➔Datasheet

➔ Brochure

➔ User Manual

➔ Wireless Tablet User Manual

Technical Specification

MEASURING UNITS: PPM or mg user selectable

MEASURING RANGES:
Range A: 0-1000ppm. User settable to e.g. 0-1ppm, 0-5ppm, 0-10ppm, 0-50ppm,0-100ppm, 0-500ppm, 0-1000ppm. Resolution:0.01ppm
Range B: 0-10000ppm. User settable to e.g. 0-10ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-5000ppm. 0-10,000ppm. Resolution: 0.1ppm
Range C. 0-100,000 ppm. User settable, with resolution of 1ppm

RESPONSE TIME: THC <1.5 secs CH4 and NMHC <2.5 secs

REPEATABILITY: <1% FSD

OXYGEN EFFECT: <2% of reading from 0% to 21% O₂ (H2He)

LINEARITY: +/- 0.5% FSD or 2% of point EN14181 – dc rel : <0.5 R2 : >0.99

DRIFT: +/-0.2ppm or 2% range per week, whichever greater NOISE +/-0.1ppm or 1% range, whichever greater

TEMPERATURE EFFECT ON ZERO: <0.15% per o C

TEMPERATURE EFFECT ON SPAN: <0.3% per o C

SAMPLE INLET PRESSURE:
With internal sample pump: -0.6 to +0.4bar
Without internal sample pump: +0.2 to +0.5bar

ACCURACY: <0.2% FSD

PRECISION: <1%

DETECTION LIMIT: 0.05mgC/m3

BYPASS FLOW SENSITIVITY: Less than 2% from 1 to 3 L/min

SAMPLE FILTER: Removable 0.4 micron PTFE 7um non removable stainless steel filter for CFID

SAMPLE CONDITION: 0-200o C (Heated version) 0-80o C non-condensing for CFID

FUEL CONSUMPTION:
Single detector: 35ml/min H2 or 180ml/min H2He
Dual detectors: 70ml/min H2 or 360ml/min H2He

AIR SUPPLY: Single detector: >1.1L/min or Dual detector: >1.6L/min

OPERATING CONDITIONS: 5-40o C ambient temperature

OUTPUTS:
0-10 Vdc
RS232
Ethernet
TCP/IP
Optional 4-20 mA

POWER REQUIREMENTS: 100 to 250Vac Optional 24VDC 600W max

REMOTE CONTROL: AK protocol via RS232 port, Ethernet Comes with S4i remote software operating system.

SIZE AND WEIGHT: 19” (w) x 133.5 (h) x 530 mm (d). Apx. 30Kg

Optional Configuration

Solar FID Type*:
HFID-THC
HFID-DNMHC

Power Supply:
110VAC/220VAC (Standard – Universal)
24VDC

Fuel Gas:
H2He (Standard)
H2 Fuel

Range Required:
0-1000ppm
0-10,000ppm (Standard)
0-100,000ppm

SOLAR FID OPTIONS:

AS90 Internal Air Purifier*:
Yes
No

Front Panel:
Blank
Removable Wireless Tablet

Pumps*:
Internal heated sample pump
Internal air pump
External heated pump
External air pump

Output* (Analogue outputs are either 0-10VDC or 4-20mA):
0-10VDC (Standard)
4-20mA (optional at extra cost)
Upgraded chart output (20 additional alarms)

MI/995 – Analogue Output SCSI Cable (optional at extra cost):
Yes
No



Notes:

– HFID-THC is a heated flame ionisation detector to measure total hydrocarbons in a sample.

– HFID-DNMHC is a heated flame ionisation with dual detector to measure methane, non-methane and total hydrocarbons in a sample.

– AS90 is a built-in heated catalyst air purifier to supply hydrocarbon free air for increased stability and drift.

– Blank Panel is provided with free issued S4i software to act as remote display and to automate coarse and fine calibration. Display: Removable 6inch Wireless Tablet screen with on-board logging facility.

– Options for either internal or external sample pump where sample is not under positive pressure. External sample pump recommended for applications operating 24/7 and for ease of servicing.

– Options for internal or external air pump for zero calibration and FID flame air supply.

– The standard I/O includes 3 contact closure alarm outputs. This upgraded option has 23 user configurable contact closure that can be used for alarms or to control external functions such as down-the-line calibration where valves to introduce calibration gas at the sample inlet point can be controlled automatically.
